Automatic Nail Box stitching

Automatic high speed MONO CARTON nail box machine

NXGN-260 automatic high-speed nail box machine is a high-speed intelligent automatic wire nail folding box integrated packaging equipment developed by our factory according to the market demand and advanced technology at home and abroad. Widely used in crafts, electronics, electrical appliances and hardware, standard parts, fasteners and other carton packaging industry.

Description

NXGN-260 automatic high-speed nail box machine is a high-speed intelligent automatic wire nail folding box integrated packaging equipment developed by our factory according to the market demand and advanced technology at home and abroad. Widely used in crafts, electronics, electrical appliances and hardware, standard parts, fasteners and other carton packaging industry.

Intelligent computer control, high-precision photoelectric tracking, touch screen human-computer interaction; A number of wear-resistant thickened belt bottoms are used to pump and feed, combined with vibration motor to assist; The host is equipped with frequency conversion high-speed linkage operation; Cardboard nailing using intelligent servo motor combined with high-speed silent nailing head can be used to nail boxes without paper boxes; Equipped with automatic counting paper lifting device, convenient for users to produce counting, is now the preferred equipment for

Carton packaging enterprises.

Additional information

Board parameter

A 180-450 mm
B 380-650 mm
K 20-30 mm
L 100-200 mm
W 80-220 mm
H 50-300 mm

Staple spacing

M min 20 mm thread row number can be adjusted, the same row can be single or double nails

Wire type

19# 20#

Corrugated paper

B/E/F-flute

Cardboard

250-650 g

Source pressure

90 L / 0.6 mpa

Supply voltage

380 V / 50 HZ

Motor power

3.6 KW

Speed

0-110 PCS/min

Dimension

L5500 X W1500 X H1900 mm

Weight

1600 Kg
